干燥或潮湿的场合，特别是车辆电器及仪表线路的安装及固定敷设。
To be used in the dry or wet situations, specially in vehicles and Instruments
电缆特性Characteristics：
采用的绝缘料具有优良的耐溶剂和耐油性能，
并具有相应温度等级的耐热性能,具有优良的耐刮性和良好耐低温性能,常规工作温度90度。
The cables have excellent oil resistance, solvent resistance,heat resistance, scrape
resistance and low temperature resistance properties due to its special insulation materials.
The normal working temperature is 90℃.
参照标准Reference standard: GB9238-88
GB9238-88
电缆结构Construction:
导体：多股精绞无氧铜丝，符合VDE0295CLASS 5标准
Conductor: copper acc. to VDE0295 CLASS 5
绝缘：105oC阻燃PVC料
Insulation: 105oC Flame Retardant PVC
颜色：颜色表示,任意
Colour: Refer to the customer’s requirement
70℃时的绝缘电阻≥109Ω.m体积电阻率
Insulation resistance at 70℃:≥109Ω.m
绝缘电压测试:Testing votage for insulation:
绝缘厚度δ≤0.5mm: 4KV 0.5mm＜δ≤1.0：6KV
Insulation thickness:δ≤0.5mm: 4KV
0.5mm＜δ≤1.0：6KV
产品耐压测试Testing votage: 2.5KV
2.5KV
如果您需要更细的导线，请查阅我公司德标电线，参数如下：
|
